Description
Rock Screener | Gravel Screener | Metso
Metso Corporation is the result of a merger,
this one between Valmet and Rauma.
The company, which came into existence in 1999,
is headquartered in Helsinki, Finland.
While the company serves many industries,
including pulp and paper, power, panelboard production
and the hydrocarbon and process industries,
some of its best-known offerings
were designed for rock and mineral processing.
Today, those machines, like the Nordberg CV100 Screener,
are used for mining, aggregate production,
quarrying and construction.
weighs 24,380 pounds.
Its single axle weighs 13,897 pounds.
It measures 27' 7" x 8' 6" x 12' 0" (LxWxH),
with an 11’ x 7’ deck.
It’s powered by a Deutz BF4L1011 32.5 kW (44 Hp)
liquid cooled diesel engine.
It features a vibrating shaker head
with direct hydraulic drive.
Its dual-deck design measures 11' x 7',
with both decks capable of accepting
assorted grids, woven wire screen cloth,
perforated steel punch plate or finger decks.
The CV 100 has a heavy duty chassis
with hydraulic front lifting leg,
riding on four 9.0 x 17.5 tires
with hydraulic wheel elevation system,
mud flaps, and air brakes.
It’s suitable for over–the–road towing
with pintle hook tow assembly,
tail lights and directional signals.
on the Nordberg CV100 mobile screen
is based on proven technology
and years of experience;
it’s hydraulically adjustable,
and provides a compact and highly reliable screening plant
that can handle a wide variety of materials on site,
reducing hauling and tipping costs
and improving productivity and profit.
Their simplicity is such
that no standby operator is required,
reducing operating costs and increasing profits.
Standard features on the CV100 include
a bolt together shakerhead, wheel brakes,
a hydraulically operated lifting system,
Sauer-Danfoss hydraulics,
automatic shut-down system
with indicator lights,
tamper-proof hour meter,
locking engine compartment,
tail lights and directional signals
and an emergency break-away system.
With so many features and benefits,
it’s a small price to pay
for a big boost to your bottom line.
