IDECO H­1000 RAMBLER BIR LARGE OIL WELL DRILLING RIG

MSRP:
Was:
Now: $3,950,000.00
(You save )
Questions? Call (973) 886-3020

Description

IDECO H­1000 RAMBLER BIR LARGE OIL WELL DRILLING RIG rebuilt to new condition




Drill Rigs for Sale


800-1,000 HP, rebuilt to new condition

by Wagner Caterpillar of Albequerque, NM

Has not been put back into service since the rebuild was completed.

CERTIFIED DETAILED APPRAISAL FOR $5,700,000, AVAILABLE. Call for link.

CAPABLE OF DRILLING TO A DEPTH OF 12,000' SAND LINE DRUM CAPABLE OF 25,000'

1. 1/8" DRILLING LINE AND GROOVING

IDECO H-­‐1000 RAMBLER BIR 800 1000 HP. WITH 7 AXLES

DRAW WORKS HAS BEEN GONE THROUGH COMPLETELY, REBUILT NEW.

DRUMSHAFT AND CATSHAFT MADE OF ASTRELOY

INSTALLED WITH NEW BEARINGS.

ROTARY DRIVE TORN DOWN AND REBUILT

NEW CLUTCH PADS AND NEW CLUTCH DRUM

INSTALLED WITH NEW SPLINED HUB.

2. NEW CATIPILLAR C-18'S 630 HP EACH

WERE INSTALLED WITH NEW 6061 TRANSMISSIONS.

RIGHT ANGLE GEAR BOXES WERE INSPECTED AND REBUILT

NEW SRR-­‐28 HYDROMATIC

WAS SENT TO PARKERSBURG REBUILT NEW.

DRAWWORKS HAS ALL NEW CHAINS,

BEARINGS AND U JOINTS.

MAIN DRUM CLUTCH HAS NEW PADS

WITH NEW CLUTCH DRUM.

ALL OILER, AIR AND HYDROLIC LINES ARE NEW.

DRILLERS CONSLOLE IS NEW.

THE IDECO H-1000 UNIT

HAS ALL NEW TIRES AND WHEEL BEARINGS

FRONT AND BACK.

ALL REAR-ENDS ARE REBUILT NEW

AND ALL GEAR BOXES ARE NEW

MAST: IDECO 358,000LB HOOK LOAD QUICKLIFT

112-­‐358 WITH RACKING BOARD COMPLETE WITH STAND PIPE

CROWN REBUILT NEW.

NEW MAIN CYLINDERS AND HYDRAULIC TONGS

CYLINDERS WERE ADDED TO MAST

RACKING BOARD WAS REBUILT NEW

WORK DONE BY DELTA OILFIELD TANK CO.

SUBSTRUCTURE: NEW 10' H X 10' W X 18' L

WITH 2'H X 10'W X 18'L PONY SUB, WINTERIZED, WITH STAIRS.

IT HAS REBUILT NEW HYDRAULIC BACK UP SYSTEM

AND ALL NEW FLOURESCENT LIGHTS

AND WIRING THAT MEETS ALL SPECIFICATIONS.

SUB WAS SANDBLASTED AND HAS NEW BEAMS

WORK DONE AT DELTA OILFIELD TANK CO.






ROTARY TABLE: IDECO 37 1/2" TABLE,

WORK BY FARLEYS MACHINE SHOP

SWIVEL: NATIONAL N-­‐815 WITH QUICK CHANGE

WORK DONE BURGESS RIG REPAIR

KELLY HOSE: 4" X 55' 5 1/4 HEX KELLY

BOP: USED 11" 5000# SCHAFFER DOUBLE GATE

ANNULAR: USED 11" 5000# HYDRIL ANNULAR

USED 3" X 4" 5000# CHOKE MANIFOLD

MUD TANKS (REFURBISHED):

SHALE TANK: EQUIPPED WITH 2 SWACO ALS SHAKERS

WITH TWO NEW 5" X 6" CIRCULATING PUMPS

WITH 50 HP. MOTORS,

1 –NEW 2 CONE DESANDER AND ONE POOR BOY GAS BUSTER,

1 AGITATOR, WITH ALL LIGHTING AND ELECTRICAL

AND WEDGE TYPE MUD GATES

SUCTION TANK: EQUIPPED WITH TWO NEW 5" X 6" CIRCULATING PUMPS

WITH 50 HP. ONE 10 CONE DESILTER,

THREE AGITATORS AND MIXING HOPPER.

COMPLETE WITH ALL LIGHTING AND ELECTRICAL.

NEW WEDGE TYPE MUD GATES.

MUD TANKS WERE REBUILT NEW

IN DELTA OILFIELD TANK'S SHOP.

MUD PUMPS: REBUILT NEW GARDNER DENVER PZ-­‐9,

AMERICAN MADE,

IN A HOUSE WITH NEW 3508 CATIPILLAR ENGINE,

1200 RPM,

AND A NEW 5" X 6" CHARGING PUMP

WITH 50 HP ELECTIRC MOTOR.

NEW DAMPNER AND NEW VALVING RADIATOR

IS INDEPENDENTLY DRIVEN WITH ELECTRIC MOTOR.

GENERATOR HOUSE:

CONTAINS 2 NEW 3406 CATIPILLAR 410 KW GENERATORS,

ALSO TWO NEW GARDNER DENVER 30HP SCREW AIR COMPRESSORS,

1 FOUR STATION REBUILT NEW ACCUMULATOR

WITH NEW REMOTE,

1 NEW 10KW ELECTRIC HEATER,

75 KVA TRANFORMER

AND A NEW COMPLETE 480 VOLT ELECTRIC PANEL.

NEW FUEL DAYTANK AND NEW OIL BUNKER INCLUDED

WATER TANK:

10'W X 38'L X 9' H 350 BBL CAPACITY

WITH 2 NEW 2" X 3" CIRCULATING PUMPS






DOGHOUSE: LIKE NEW 8'W X 18'L

CONTAINS NEW ELECTRIC PANEL AND LOCKERS.

HAS ELECTRICAL CONTROLS FOR EQUIPMENT IN DOGHOUSE.

DOGHOUSE DROPS INTO WATER TANK.

HANDS CHANGE AND PARTS HOUSE:

CONTAINS LOCKERS AND SHELVING FOR PARTS.

RIG COMPLETE WITH NEW ALL LIGHTS AND ELECTRICAL

MARTIN DECKER DIAPHRAM AND INDICATOR

FUEL TANK: 8,000 GALLON WITH NEW ELECTRIC PUMPS

NEW CAT WALK:

42" H X 4' W X 52' L WITH NEW BEAVER SLIDE

COMPLETE NEW SET OF STAIRS, RAILINGS AND TARPS

RAMPS: 3 PIECE (2 ­‐ 2' H X 71'L AND 1 - 9'10" W X 34'5" L)

AMERICAN MADE IN NAVASOTA, TEXAS

IN TUBOSCOPE

18,000 FEET OF NEW G-­105 16.60 DRILL PIPE,

INLAID HARDBAND, INTERNALLY COATED

AND MADE-­‐UP AND BROKE OUT TWICE

BY TUBOSCOPE IN HOUSTON, TEXAS (NEVER BEEN USED)






AMERICAN MADE IN NAVASOTA, TEXAS

IN TUBOSCOPE

-­‐ 21 NEW 6 1/2" SPIRAL DRILL COLLARS (NEVER BEEN USED)

21 4 1/2" SPIRAL WT. PIPE

6 PIPE BASKETS

3 PIPE RACKS

ALL ELECTRICAL WORK DONE WAS BY ROCKY MOUNTAIN ELECTRIC

CANVAS

USED HANDLING TOOLS

USED TONGS

USED ELEVATOR

SPARE EQUIPMENT

6061 Transmission

1 1/8" Lebus grooving

Spare drive lines and U-joints

Rebuilt new main hydraulic cylinders

Set of brake bands

Set of cables for doghouse and water combo

Both catheads that were taken off

CALL FOR APPRAISAL DOCUMENT






BUY IT NOW !!

This drill rig is located in Colorado, USA

We make every effort to accurately represent the condition

of all items advertised and or represented.

This machine is sold on an as-is basis,

with no warranty, express or implied.

(Standard selling Practice for the industry)

For this reason, we strongly encourage and support

a prebuy inspection of any item

before you purchase it.

Please understand I don't own this IDECO H­1000 RAMBLER BIR personally

I am a full time broker selling for a customer

My goal is to bring the buyer and seller together

I do my very best to tell you what I know

Do You Need Help Marketing Your

Equipment, Boat, Plane, Car or Truck?

Your Questions and Comments Welcome 24/7

Contact Jay Trevorrow

Voicemail or Text: 973-886-3020

Email: jay@ironmartonline.com

Please Leave a Detailed Email or Voicemail


Jay Trevorrow


Rebuilt to Like New Condition:
Wagner Caterpillar, ABQ, NM
Hours Since Rebuild:
0 / Unused
Extensive Work Done on All Components:
See Below for Details
12,000' Drill Depth:
25,000' Sand Line Drum
Mast:
IDECO 358,000LB HOOK LOAD QUICKLIFT
Much More More Info/Photos:
See Below or Call for Appraisal Document
Location:
Colorado, USA
Contact:
Jay Trevorrow: 973-886-3020
